AMC-SK45 automated cryogenic biological sample storage system is a vapor-phase liquid nitrogen storage equipment with compact design.
Fully-automated with high efficiency SBS rack access and single tube retrieval; compatible with tubes of various specifications.
Dimensions (WDH): 1,780 x 2,380 x 2,650 mm
Dimensions (WDH): 5.84 x 7.81 x 8.69 ft
Storage Capacity: ≥ 114,900 cryotubes (0.5mL)
Storage Capacity: ≥ 165,100 cryotubes (0.75mL)
Storage Capacity: ≥ 78,600 cryotubes (1mL)
Storage Capacity: ≥ 60,400 cryotubes (2mL)
Voltage/Frequency/Current: 220V / 50HZ / 16 A
Weight (KG): 2250kg
Standby Power (W): ≤ 350
Operating Power (W): ≤ 1,200
Installation Power (W): ≤ 3,500
LN2 consumption: 30- 32kg/ day
System: OBS-Cyber
Certificate: CE
Product Feature
Rack-cassette storage structure, support automated SBS rack access and compatible with tubes of various specifications.
Support automated SBS rack access and compatible with tubes of various specifications.
Modular functional components with easy maintenance, excellent insulation, compact, and large capacity, single tube retrieval.
Cryogenic protection for tube-picking area, dehumidification system minimizes frost formation.
Automatic liquid nitrogen replenishment with liquid level and temperature warning
Equipped with light-rail for multi-equipment connection to construct unmanned biobanks for efficient and precise sample delivery.
Built-in batch scanning and single tube scanning functions.
The system provides an open API interface to integrate data with LIS/HIS/CIS systems.
Offer GMP and scientific research modes with user friendly interface.
Support intelligent inventory management, optimizing storage space utilization.
